Hirth Coupling Index Table - HI Ø1000
Sub-arcsecond angular precision for demanding multi-face machining operations.
HHI-1000x1000
HHI-1000x1000 Product Specifications
| Item | Data |
|---|---|
| Application | Horizontal |
| Installation Mode | Add-on |
| Table diameter(mm) | □1000x1000 |
| Diameter of center through hole(mm) | Ø50x27deep |
| Table height (Horizontal)(mm) | 400 |
| Table T-slot width(mm) | 22H7 |
| Guide block width(mm) | 18h7 |
| Transmission Mechanisms | Worm & Worm Gear |
| Min. increment(deg.) | 1 or 5 |
| Indexing precision(sec.) | ±5 |
